Applications
·Office space: Business
buildings, government agencies, etc.
·Science and education
units: Universities, research institutes, kindergartens, libraries, museums,
etc.
·Commercial service
places: Supermarkets, business buildings, hotels, banks, convention centers,
etc.
·Leisure and
entertainment venues: Stadiums, parks, scenic spots, playgrounds, leisure
clubs, etc.
·Transportation stations:
Bus stations, railway stations, high-speed rail stations, subway stations,
ferries, airports, etc.
Features
•The design is reasonable
and reliable, the noise is small, the operation is stable, and the service life
is long.
•The wings open very
fast, effectively preventing trailing and increasing the speed of travel.
•After the power is
turned off, the wings automatically open to form a transparent channel.
•Directional prompt LED
light.
•pairs of infrared
sensors to prevent pedestrians from entering the channel illegally
•Anti-backlash,
pedestrians enter the channel from the opposite direction and immediately call
the police.
•Anti-tailing, preventing
non-permitted situations of too many people at one time.
•The automatic reset
function
•compatible with various
smart cards such as IC and ID card.
•can be extended to an
automatic identification system to achieve functions such as access control,
attendance, and charging
Specification
•Material: 304 stainless
steel, material thickness: 1.5mm, cover thickness: 2mm Internal structure:
steel frame structure
•Cabinet size: 1200*300*980
•Channel width: 550MM
•Wing material: Acrylic,
etc.
•Wing color: blue, red
•voltage: DC24V
•Control signal: relay
signal input
•Light Tips: Green light
passes, red light prohibits access light working power: DC12V±5%
•Passing speed: 30
person/min read head installation position: 2
•Control panel
installation position: 2
•Gate opening and closing
time: 0.4 second environment
•Temperature: -15 degrees
to 60 degrees
•Relative humidity: ≤90%, no condensation
