Features
·TFT Color display, Elegant,
·Standard 26/34 Bits Wiegand output format, which can be compatible with any kind of Access Controller,
·Dustproof, waterproof features, suitable for any installation site,
·WDT watchdog, having a power-on self-test function,
·Fast fingerprint matching speed, 480 fingerprints within one second,
·500dpi optical fingerprint sensor, anti scratch,
·The world s leading fingerprint algorithm, refusing false fingerprints,
·Support Chinese and English operation menu,
·Background image and company Logo display can be replaceable,
·Display: card number, name, employee number, a variety of information,
Applications
·Security Reader of Access Control
·Networked security for IBS buildings, financial and research institutes
·Time & Attendance for offices and factories
Specification
| Description： | Fingerprint reader, FP Standalone |
| Interface： | TCP/IP |
| CPU： | 400MHz DSP |
| Memory： | 4MB flash + 8MB RAM |
| Fingerprint Sensor： | 500 dpi optical sensor |
| Fingerprint Identification Speed： | 1 to 2,000 identification in 1sec |
| Fingerprint Capacity： | 480 templates |
| RF Card： | 125KHz |
| External Reader： | Wiegand Input Reader |
| Display： | None |
| Keypad： | None |
| Operation Modes： | Card/FP, Card + FP, ID+FP |
| Wiegand Output： | Configurable, 26/34 bits |
| Operating Voltage： | 12VDC |
| Dimension： | 135mm×58mm×45mm |
