Metal Case | Optional Color | Touchpad | Art Background Light |
Features
RF Proximity Options - P:HID/Awid/EM/KKID Prox,125KHz;U:Mifare/DesFire, Mifare Sector, CPU | |
Metal Case, beautiful and Anti vandal | |
Touchpad Button | |
Wiegand 26/34Bits Output, can be for most of access controllers | |
OSDP (Open Supervised Device Protocol) Output, longer distance to panel, more security | |
IP65 waterproof | |
Low consumption, save energy, More stable | |
Double color LED background light, Blue and Green, easy to operate in dark | |
Fit to American electronic Standard back box |
Model Definition
Specification
Type: | EM、HID、AWID、KKID |
Cards: | EM4100,HID1386,KKID |
Range: | 10cm |
Frequency : | 125KHz |
Encryption: | Manchester |
Voltage: | 7—15VDC |
Current: | ≤80mA |
Temperature: | -20’C ~ 70’C |
Humidity: | 5%--95% |
Dimension: | 91mm×91mm×30mm |
