Applications
•Office space: Business buildings, government agencies, etc.
•Science and education units: Universities, research institutes, kindergartens, libraries, museums, etc.
•Commercial service places: Supermarkets, business buildings, hotels, banks, convention centers, etc.
•Leisure and entertainment venues: Stadiums, parks, scenic spots, playgrounds, leisure clubs, etc.
•Transportation stations: Bus stations, railway stations, high-speed rail stations, subway stations, ferries, airports, etc.
Specification
•Assembly: Chassis, movement, control board and power supply
•Housing: Brushed stainless steel, SUS304
•Dimensions: L1630*W1450*H2300mm
•Turntable : One-way/two-way
•Rotate: 120 degree
•Opening time:0.2 seconds
•Central pole: φ102mm
•Arm diameter : 38mm*L600mm*3
•The biggest bearing force of the pole : 50KG
•Input:AC220V±10%,50Hz±4%, DC24VDC12V
•Environment: Indoor and outdoor recommended rainproof shed
•Operating temperature: -10℃～60℃
•Relative humidity: 5% ～95%, no condensation
•Speed:>30 people / minute,
•Aisle Width:550～700mm
•Weight:250kg
•Input interface: Dry contact signal, 12V level or 12V pulse width ≥100ms
•Communication Interface:RS485 (distance ≤1200 meters), TCP/IP
•Life span : Continuous opening and closing more than 8 million times
