Features:
Power over Ethernet
Wireless HUB
Lock Monitor
Flow Control
Hardware Features:
 |
Flexible Collocation - Family Member: DPU3012POE, DPU3024POE, DPU3044POE, DPU3048POE, DPU3000-W8 - Easy for 1, 2, 4 doors, and combine |
 |
Ultra Performance - 1:100,000 matches in 0.1 second |
 |
Whole Wiegand Signal Compatible - Compatible with all Wiegand reader formats from 24 to 72 Bits |
 |
RS485 Extension -Supports equipment through built-in 2 pcs RS485 bus |
 |
Power over Ethernet - Power supply through a single CAT5/6 wiring |
 |
Flow Control - Flexible programmable flow control between inputs and outputs |
 |
Wireless door sensor - Wireless Door Sensor can be configured to door. |
 |
Wireless REX Button - Wireless REX Button can be configured to door. |
 |
On-Line and Off-Line seamless operation -On-Line: connected to server, Off-Line: Stand-Alone, not connected to server |
Specifications
| CPU： | 32 bits ARM® Cortex-M4 Processor |
| Cardholder Capacity： | 100,000 users |
| Log Capacity： | 200,000 |
| Communication： | TCP/IP 100MBPS Auto Sensing |
| PoE： | 803.11af |
| Wireless： | 433MHz to locks, up to 8 locks 8 channels to avoid conflict Same Floor: Max 8*8=64 doors |
| RS485： | 2 pcs for future equipment |
| Input (Virtual)： | Wireless REX exit buttons and Door sensors |
| Aux Input： | 4 pcs |
| Aux Output： | 2 pcs, Dry Contact |
| Operating Temp： | - 20℃ ~ 65℃ |
| Operating Voltage： | 12vDC, 200mA (Controller only) 12vDC, 3A (Reader connected) |
| Dimensions (mm)： | W138×H244×D33 |
| Certificates： | CE, FCC, RoHS |
System diagrams
