| Maximum Read Range | 100mm Bluetooth Range: ≤15m |
| Frequency | ASK at 125KHz; CPU: 13.56MHz |
| Dual Frequencies Card |
P: Proximity, HID, AWID, EM, KKID. U: DesFire, NFC, Mifare Secror, CPU |
| OSDP | V2.17+ |
| Multi Wiegand Output |
AWID: Up to 58 bits EM, 2308: 26/34 HID: 26/27/34/35/37 bits KKID: 34/50 bits Mifare: 34 Bits Desfire: 66 Bits |
| Waterproof | IP66 |
| Operating Temp | - 20’C ~ 50’C |
| Operating Voltage | 12VDC, 300mA; POE, Power Over Ethernet |
| Operating Current | ≤120mA |
| Standby Current | ≤80mA |
| Dimensions (mm) | W86 x H86 x D25 |
| Weight | 150g |
| Certificates | CE, FCC, RoHS |
