Features
⚫ 32 bit processor with 4M bit data memory
⚫ Built-in Proximity, Mifare/DesFire Reader
⚫ Wiegand / OSDP reader input
⚫ Compatible with all Wiegand reader format from 24 to 72 Bits
⚫ Bluetooth technology, support KeyPass APP
⚫ OSDP output working as a reader
⚫ Blue backlight & TouchPad
⚫ Work Mode: Card / PIN, Card + PIN, PIN only, NFC, Bluetooth (Optional).
⚫ TFT color display to indicate Clock, Company, Name, Card No.
⚫ Communication: TCP/IP
⚫ Events Flow Control
⚫ Supports 500 Visitors
⚫ Including UDP Protocol
⚫ CE, FCC, RoHS approval
Specification
| CPU | ARM® Cortex-M3 |
| 1 Door Relay (NC/NO) 1 Door Sensor (NO) 1 Exit Button 1 Auxiliary Output Relay 2 Auxiliary Inputs 1 Wiegand Reader Input 1 OSDP Reader Input / Output (Optional) |
|
| Supports online computer polling | |
| Communication Port: | TCP, 100M |
| 15 Time Groups for 1 door | |
| Card Capacity: | 30,000 |
| Emergency Cards: | 10 |
| Transaction Storage: | 100,000 events |
| Maximum read range*: | E: 150mm, H: 10mm; M: 50mm (2.00 in.) |
| Modulation: | P: 125KHz; U: 13.56MHz |
| Compatible cards: | EM Proximity card; HID & Awid proximity; U: Mifare, Desfire and CPU cards, ISO14443A |
| Operating Voltage: | 12VDC(±10%) |
| Operating Current: | ≤100mA |
| Standby Current: | ≤80mA |
| Working Temperature: | -30°C to 65°C (- 22°F to 150°F) |
| Operating Humidity: | 0 to 95% |
| Dimensions: | 161×66×25mm |
| Weight: | 390g |
